LDD-1000H - Mean Well

LDD-1000H Details

• Manufacturer Part Number:

  LDD-1000H

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• Package Description:

  PACKAGE-24/9

• ECCN Code:

  EAR99

• HTS Code:

  8542.39.00.60

• Factory Lead Time:

  19 Weeks, 3 Days

• Manufacturer:

  Mean Well

• YTEOL:

  0

• Interface IC Type:

  LED DISPLAY DRIVER

• JESD-30 Code:

  R-PDMA-P9

• Length:

  31.8 mm

• Multiplexed Display Capability:

  NO

• Number of Functions:

  1

• Number of Terminals:

  9

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  DMA

• Package Shape:

  RECTANGULAR

• Package Style:

  MICROELECTRONIC ASSEMBLY

• Peak Reflow Temperature (Cel):

  240

• Seated Height-Max:

  12.25 mm

• Supply Voltage-Max:

  56 V

• Supply Voltage-Min:

  9 V

• Supply Voltage-Nom:

  48 V

• Surface Mount:

  NO

• Temperature Grade:

  INDUSTRIAL

• Terminal Form:

  PIN/PEG

• Terminal Pitch:

  2.54 mm

• Terminal Position:

  DUAL

• Time@Peak Reflow Temperature-Max (s):

  10

• Width:

  20.3 mm
