LDH-65-1050 - Mean Well

LDH-65-1050 Details

• Manufacturer Part Number:

  LDH-65-1050

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• Date Of Intro:

  2020-07-20

• Manufacturer:

  Mean Well

• YTEOL:

  7

• Analog IC - Other Type:

  DC-DC LED POWER SUPPLY MODULE

• Approvals:

  BS, EN, EAC

• Efficiency (Main Output):

  91.5%

• Input Voltage-Max:

  32 V

• Input Voltage-Min:

  9.5 V

• Input Voltage-Nom:

  12 V

• JESD-30 Code:

  R-XXMA-P6

• Length:

  75 mm

• Number of Functions:

  1

• Number of Outputs:

  1

• Number of Terminals:

  6

• Operating Temperature-Max:

  60 °C

• Operating Temperature-Min:

  -40 °C

• Output Current-Max:

  1.05 A

• Output Voltage-Max:

  60 V

• Output Voltage-Min:

  12.5 V

• Package Body Material:

  UNSPECIFIED

• Package Code:

  XMA

• Package Equivalence Code:

  MODULE,6LEAD,1.4

• Package Shape:

  RECTANGULAR

• Package Style:

  MICROELECTRONIC ASSEMBLY

• Protections:

  SHORT CIRCUIT, OVER VOLTAGE

• Seated Height-Max:

  23.7 mm

• Surface Mount:

  NO

• Technology:

  HYBRID

• Terminal Form:

  PIN/PEG

• Terminal Position:

  UNSPECIFIED

• Total Power Output-Max:

  63 W

• Trim/Adjustable Output:

  NO

• Width:

  53 mm
