- Datasheet
- Stock & Prices $ Price & Stock for LE88286TQC
- Part Number LE88286TQC
- Manufacturer Microchip
- Pin Count 65
- Part Category Integrated Circuit
- Package Category Quad Flat No-Lead
- Footprint Name Quad Flat No-Lead - 64-Pin QFN_2023
- Released Date Aug 13, 2023
- Last Modified Date Aug 13, 2023 6:36 AM UTC
- Pinout / Pin List Click Here (Member Only)
LE88286TQC Details
-
Manufacturer Part Number:
LE88286TQC
-
Rohs Code:
Yes
-
Part Life Cycle Code:
Obsolete
-
Package Description:
QFN-64
-
Pin Count:
64
-
Manufacturer Package Code:
VQFN-64
-
Country Of Origin:
Thailand
-
ECCN Code:
EAR99
-
HTS Code:
8542.31.00.01
-
Manufacturer:
Microchip Technology Inc
-
YTEOL:
0
LE88286TQC Frequently Asked Questions (FAQs)
-
Microchip provides a recommended PCB layout guide in their application note AN2005, which includes guidelines for component placement, routing, and thermal management to ensure optimal performance and minimize EMI.
-
The LE88286TQC has multiple power modes, including a low-power mode. To configure the device for low-power mode, refer to the 'Power Management' section in the datasheet, which provides details on the necessary register settings and clock control.
-
The LE88286TQC is rated for operation from -40°C to +85°C, but it's essential to note that the device's performance and reliability may degrade at extreme temperatures. Ensure proper thermal management and consider derating the device for high-temperature applications.
-
Although the LE88286TQC is primarily designed for automotive applications, it can be used in non-automotive applications as well. However, ensure that the device meets the specific requirements of your application, and consult with Microchip's support team if necessary.
-
Microchip recommends using high-quality, low-ESR decoupling capacitors with a value of 100 nF to 1 μF, placed as close as possible to the device's power pins. Refer to the 'Decoupling and Bypassing' section in the datasheet for more information.
Trust Checks
Community Provided
System Verified
Community Approved
LE88286TQC Overview
Use the download button to access the LE88286TQC schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like LE882,
or try a keyword search, such as Analog Transmission Interfaces
