LFCG-1000+ - Mini-Circuits

Description: LTCC Low Pass Filter, DC - 1000 MHz, 50Ω

Download LFCG-1000+ Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
LFCG-1000+ - Mini-Circuits PCB footprint - Other - Other - LFCG-1000+-1
click to zoom
3D Models
LFCG-1000+ - Mini-Circuits  - 3D model - Other - LFCG-1000+-1
click to zoom

LFCG-1000+ Details

  • Manufacturer Part Number:

    LFCG-1000+

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Package Description:

    EIA STD PACKAGE SIZE 0805, LTCC, 8 PIN

  • ECCN Code:

    EAR99

  • Manufacturer:

    Mini-Circuits

  • YTEOL:

    8

  • Average Input Power:

    5.5 W

  • Filter Type:

    CERAMIC LPF

  • Input/Output Impedance:

    50 OHM

  • JESD-609 Code:

    e3

  • Mounting Type:

    SURFACE MOUNT

  • Number of Sections-Max:

    1

  • Number of Sections-Min:

    1

  • Terminal Finish:

    Tin (Sn) - with Nickel (Ni) barrier
