LFD21891MMF3D931 - Murata Electronics

Description: Signal Conditioning 869.50MHz 500mW Silicon Labs

Download LFD21891MMF3D931 Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
LFD21891MMF3D931 - Murata Electronics PCB footprint - Other - Other - LFD21891MMF3D931-1
click to zoom
3D Models
LFD21891MMF3D931 - Murata Electronics  - 3D model - Other - LFD21891MMF3D931-1
click to zoom

LFD21891MMF3D931 Details

  • Manufacturer Part Number:

    LFD21891MMF3D931

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • ECCN Code:

    EAR99

  • HTS Code:

    8529.90.98.00

  • Factory Lead Time:

    12 Weeks

  • Manufacturer:

    Murata Manufacturing Co Ltd

  • YTEOL:

    7

  • Filter Type:

    DUPLEXER

  • Height:

    0.7 mm

  • Length:

    2 mm

  • Operating Temperature-Max:

    85 °C

  • Operating Temperature-Min:

    -40 °C

  • Packing Method:

    TR, EMBOSSED, 7 INCH

  • Receive Center Frequency:

    869.5 MHz

  • Transmit Center Frequency:

    869.5 MHz

  • Width:

    1.25 mm

LFD21891MMF3D931 Frequently Asked Questions (FAQs)
