LM-NP-1003 - Bourns

LM-NP-1003 Details

• Manufacturer Part Number:

  LM-NP-1003

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• ECCN Code:

  EAR99

• Manufacturer:

  Bourns Inc

• YTEOL:

  0

• Additional Feature:

  TURNS RATIO: 1:1

• Approvals:

  UL

• Height:

  12.6 mm

• JESD-609 Code:

  e3

• Length:

  17.7 mm

• Mounting Feature:

  THROUGH HOLE MOUNTED

• Operating Frequency-Max:

  3.5 kHz

• Operating Frequency-Min:

  0.2 kHz

• Operating Temperature-Max:

  60 °C

• Operating Temperature-Min:

  -10 °C

• Primary Impedance:

  600 OHMS

• Secondary Impedance:

  600 OHMS

• Surface Mount:

  NO

• Terminal Finish:

  Tin (Sn)

• Transformer Type:

  TELECOM TRANSFORMER

• Width:

  17.7 mm
