LM2931CTG - onsemi

LM2931CTG Details

• Manufacturer Part Number:

  LM2931CTG

• Brand Name:

  onsemi

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• Part Package Code:

  TO-220 5 LEAD

• Pin Count:

  5

• Manufacturer Package Code:

  314D-04

• ECCN Code:

  EAR99

• HTS Code:

  8542.39.00.60

• Manufacturer:

  onsemi

• YTEOL:

  0

• Adjustability:

  ADJUSTABLE

• Dropout Voltage1-Max:

  0.6 V

• Dropout Voltage1-Nom:

  0.16 V

• JESD-30 Code:

  R-XSFM-T5

• JESD-609 Code:

  e3

• Line Regulation-Max (%/V):

  1.25

• Number of Functions:

  1

• Number of Outputs:

  1

• Number of Terminals:

  5

• Operating Temperature TJ-Max:

  150 °C

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -40 °C

• Output Current1-Max:

  0.1 A

• Output Voltage1-Max:

  29.5 V

• Output Voltage1-Min:

  2.7 V

• Package Body Material:

  UNSPECIFIED

• Package Code:

  SFM

• Package Equivalence Code:

  SIP5,.1,67TB

• Package Shape:

  RECTANGULAR

• Package Style:

  FLANGE MOUNT

• Packing Method:

  RAIL

• Qualification Status:

  Not Qualified

• Regulator Type:

  ADJUSTABLE POSITIVE SINGLE OUTPUT LDO REGULATOR

• Surface Mount:

  NO

• Technology:

  BIPOLAR

• Terminal Finish:

  Tin (Sn)

• Terminal Form:

  THROUGH-HOLE

• Terminal Pitch:

  1.7 mm

• Terminal Position:

  SINGLE
