The maximum voltage that can be applied to the input pins is the supply voltage (VCC) + 0.3V. Exceeding this voltage can cause damage to the device.
To prevent oscillation, add hysteresis to the comparator by connecting a resistor and capacitor between the output and the non-inverting input. This will help to stabilize the output.
The minimum input voltage required for the comparator to function correctly is 2V. Operating the device below this voltage may result in incorrect output states.
No, the LM393NG is a comparator, not an amplifier. It is designed to compare two input voltages and output a digital signal, not to amplify a signal.
The pull-up resistor value depends on the load current and the desired output voltage. A general rule of thumb is to choose a value between 1kΩ and 10kΩ. A higher value will reduce power consumption but may increase the output rise time.
Trust Checks
This model has been built in collaboration with the manufacturer.
Manufacturer Collaborated
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored
LM393NG Overview
Use the download button to access the LM393NG schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like LM393,
or try a keyword search, such as Comparators
