LM75AD - NXP

LM75AD Details

• Manufacturer Part Number:

  LM75AD

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Not Recommended

• Package Description:

  SOP-8

• HTS Code:

  8542.39.00.01

• Manufacturer:

  NXP Semiconductors

• YTEOL:

  3

• Accuracy-Max (Cel):

  3 Cel

• Additional Feature:

  THERMAL WATCHDOG

• Body Breadth:

  3.9 mm

• Body Height:

  1.35 mm

• Body Length or Diameter:

  4.9 mm

• Housing:

  PLASTIC

• JESD-609 Code:

  e4

• Mounting Feature:

  SURFACE MOUNT

• Number of Bits:

  11

• Number of Terminals:

  8

• Operating Current-Max:

  1 mA

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -55 °C

• Output Interface Type:

  2-WIRE INTERFACE

• Output Voltage-Min:

  0.4 V

• Package Body Material:

  PLASTIC/EPOXY

• Package Equivalence Code:

  SOP8,.25

• Package Shape/Style:

  RECTANGULAR

• Sensors/Transducers Type:

  TEMPERATURE SENSOR,SWITCH/DIGITAL OUTPUT,SERIAL

• Supply Voltage-Max:

  5.5 V

• Supply Voltage-Min:

  2.8 V

• Surface Mount:

  YES

• Terminal Finish:

  Nickel/Palladium/Gold/Silver (Ni/Pd/Au/Ag)

• Termination Type:

  SOLDER
