LP4-EE-1-R-W-A-T-G - E-Switch

LP4-EE-1-R-W-A-T-G Details

• Manufacturer Part Number:

  LP4-EE-1-R-W-A-T-G

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Direct Group:

  SH10010103YY01010YY10YYYYYYYYYYYY

• Similar Group:

  SH10010103YY01010YY10

• ECCN Code:

  EAR99

• HTS Code:

  8536.50.90.33

• Manufacturer:

  E-Switch Inc

• YTEOL:

  8

• Actuator Travel:

  1.4986 mm

• Actuator Type:

  PUSHBUTTON

• Additional Feature:

  WITH LED

• Body Breadth:

  8.7376 mm

• Body Color:

  WHITE

• Body Length or Diameter:

  10.4902 mm

• Contact Current(DC)-Max:

  0.1 A

• Contact (DC) Max Rating R Load:

  0.1A@30VDC

• Contact Resistance:

  0.05 mΩ

• Contact Voltage(DC)-Max:

  30 V

• Dielectric Withstand Volts:

  500VAC V

• Illumination:

  NON-ILLUMINATED

• Insulation Resistance:

  100000000 Ω

• Mounting Feature:

  THROUGH HOLE-RIGHT ANGLE

• Operating Temperature-Max:

  70 °C

• Operating Temperature-Min:

  -20 °C

• PCB Hole Count:

  10

• Surface Mount:

  NO

• Switch Action:

  LATCHED

• Switch Function:

  DPDT

• Switch Type:

  PUSHBUTTON SWITCH

• Termination Type:

  SOLDER
