LPC55S16JBD100Y - NXP

Description: ARM® Cortex®-M33 LPC55S1x Microcontroller IC 32-Bit 150MHz 256KB (256K x 8) FLASH 100-HLQFP (14x14) ,1.8V ~ 3.6V ,-40°C ~ 105°C

Download LPC55S16JBD100Y Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
Send part feedback
Symbol
LPC55S16JBD100Y - NXP - PCB symbol
click to zoom
PCB Footprints
LPC55S16JBD100Y - NXP PCB footprint - Quad Flat Packages - Quad Flat Packages - SOT1570-3
click to zoom
3D Models
LPC55S16JBD100Y - NXP - 3D model - Quad Flat Packages - SOT1570-3
click to zoom

LPC55S16JBD100Y Details

  • Manufacturer Part Number:

    LPC55S16JBD100Y

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • HTS Code:

    8542.31.00.30

  • Manufacturer:

    NXP Semiconductors

  • YTEOL:

    9

  • Moisture Sensitivity Level:

    3

  • Peak Reflow Temperature (Cel):

    260

  • Time@Peak Reflow Temperature-Max (s):

    30

  • uPs/uCs/Peripheral ICs Type:

    MICROCONTROLLER, RISC

Trust Checks

This model has been provided by an expert contributor.
Expert Contribution
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored

LPC55S16JBD100Y Overview

Use the download button to access the LPC55S16JBD100Y schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like LPC55, or try a keyword search, such as Microcontrollers
