LQH32DN331K23L - Murata Electronics

LQH32DN331K23L Details

• Manufacturer Part Number:

  LQH32DN331K23L

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  CHIP

• Country Of Origin:

  Japan

• ECCN Code:

  EAR99

• HTS Code:

  8504.50.80.00

• Factory Lead Time:

  10 Weeks

• Manufacturer:

  Murata Manufacturing Co Ltd

• YTEOL:

  7

• Case/Size Code:

  1210

• Core Material:

  FERRITE

• DC Resistance:

  13 Ω

• Inductance-Nom (L):

  330 µH

• Inductor Application:

  POWER INDUCTOR

• Inductor Type:

  GENERAL PURPOSE INDUCTOR

• Number of Functions:

  1

• Number of Terminals:

  2

• Package Height:

  2 mm

• Package Length:

  3.2 mm

• Package Style:

  SMT

• Package Width:

  2.5 mm

• Packing Method:

  TR, EMBOSSED, 7 INCH

• Rated Current-Max:

  0.06 A

• Self Resonance Frequency:

  5.6 MHz

• Shape/Size Description:

  RECTANGULAR PACKAGE

• Shielded:

  NO

• Surface Mount:

  Reflow soldering

• Terminal Placement:

  DUAL ENDED

• Terminal Shape:

  WRAPAROUND

• Test Frequency:

  1 MHz

• Tolerance:

  10%
