LRPS-2-11J+ - Mini-Circuits

Description: 2 Ways Core & Wire Power Splitter, 20 - 2000 MHz, 50

Download LRPS-2-11J+ Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
LRPS-2-11J+ - Mini-Circuits PCB footprint - Other - Other - LRPS-2-11J+-1
click to zoom
3D Models
LRPS-2-11J+ - Mini-Circuits  - 3D model - Other - LRPS-2-11J+-1
click to zoom

LRPS-2-11J+ Details

  • Manufacturer Part Number:

    LRPS-2-11J+

  • Pbfree Code:

    Yes

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • ECCN Code:

    EAR99

  • Manufacturer:

    Mini-Circuits

  • YTEOL:

    7.15

  • Characteristic Impedance:

    50 Ω

  • Construction:

    COMPONENT

  • Input Power-Max (CW):

    30 dBm

  • Insertion Loss-Max:

    1.5 dB

  • Isolation-Min:

    15 dB

  • JESD-609 Code:

    e3

  • Mounting Feature:

    SURFACE MOUNT

  • Number of Terminals:

    6

  • Operating Frequency-Max:

    2000 MHz

  • Operating Frequency-Min:

    20 MHz

  • Operating Temperature-Max:

    85 °C

  • Operating Temperature-Min:

    -40 °C

  • Package Equivalence Code:

    SMDIP6,.4

  • RF/Microwave Device Type:

    SPLITTER AND COMBINER

  • Surface Mount:

    YES

  • Terminal Finish:

    Tin (Sn) - with Nickel (Ni) barrier

  • VSWR-Max:

    1.58

LRPS-2-11J+ Frequently Asked Questions (FAQs)

  • Mini-Circuits provides a recommended PCB layout and footprint in their application notes, which can be found on their website. It's essential to follow these guidelines to ensure optimal performance and minimize parasitic effects.
  • The LRPS-2-11J+ has a 50 ohm input and output impedance. To impedance match, use a pi-network or a T-network topology with resistors and capacitors. You can also use simulation software like ADS or AWR to optimize the matching network.
  • The maximum power handling of the LRPS-2-11J+ is 1W. Exceeding this power limit can cause damage to the device. Make sure to derate the power handling based on the operating frequency and temperature.
  • Yes, the LRPS-2-11J+ is designed for high-reliability applications and is suitable for use in space-constrained environments. However, it's essential to follow proper PCB design and assembly practices to ensure reliability and performance.
  • Common issues with the LRPS-2-11J+ include poor return loss, high insertion loss, or oscillations. To troubleshoot, check the PCB layout, impedance matching, and power handling. Use a vector network analyzer to measure the device's S-parameters and identify the root cause of the issue.
