LT1006CN8 - Analog Devices

Description: Precision Amplifiers LT1006 - Precision, Single Supply Op Amp

Download LT1006CN8 Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
Send part feedback
Symbol
LT1006CN8 - Analog Devices - PCB symbol
click to zoom
PCB Footprints
LT1006CN8 - Analog Devices PCB footprint - Dual-In-Line Packages - Dual-In-Line Packages - N8 8-Lead PDIP
click to zoom
3D Models
LT1006CN8 - Analog Devices - 3D model - Dual-In-Line Packages - N8 8-Lead PDIP
click to zoom

LT1006CN8 Details

  • Manufacturer Part Number:

    LT1006CN8

  • Part Life Cycle Code:

    Obsolete

  • Package Description:

    DIP-8

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.33.00.01

  • Manufacturer:

    Analog Devices Inc

  • YTEOL:

    0

  • Amplifier Type:

    OPERATIONAL AMPLIFIER

  • Average Bias Current-Max (IIB):

    0.023 µA

  • Common-mode Reject Ratio-Nom:

    114 dB

  • Input Offset Voltage-Max:

    330 µV

  • JESD-30 Code:

    R-PDIP-T8

  • JESD-609 Code:

    e0

  • Moisture Sensitivity Level:

    1

  • Neg Supply Voltage Limit-Max:

    -22 V

  • Neg Supply Voltage-Nom (Vsup):

    -15 V

  • Number of Functions:

    1

  • Number of Terminals:

    8

  • Operating Temperature-Max:

    70 °C

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Code:

    DIP

  • Package Shape:

    RECTANGULAR

  • Package Style:

    IN-LINE

  • Qualification Status:

    Not Qualified

  • Seated Height-Max:

    3.937 mm

  • Slew Rate-Nom:

    1.2 V/us

  • Supply Voltage Limit-Max:

    22 V

  • Supply Voltage-Nom (Vsup):

    15 V

  • Surface Mount:

    NO

  • Technology:

    BIPOLAR

  • Temperature Grade:

    COMMERCIAL

  • Terminal Finish:

    Tin/Lead (Sn/Pb)

  • Terminal Form:

    THROUGH-HOLE

  • Terminal Pitch:

    2.54 mm

  • Terminal Position:

    DUAL

  • Width:

    7.62 mm

LT1006CN8 Frequently Asked Questions (FAQs)

  • A good PCB layout for the LT1006CN8 involves keeping the input and output traces short and separate, using a solid ground plane, and placing the bypass capacitors close to the device. Additionally, it's recommended to use a low-ESR capacitor for the output filter capacitor.
  • To ensure stability, make sure to follow the recommended component values and PCB layout guidelines. Additionally, check that the output capacitor is within the recommended range, and that the input voltage is within the specified range. Also, consider adding a small capacitor (e.g. 10nF) between the output and ground to improve stability.
  • The maximum power dissipation of the LT1006CN8 is dependent on the ambient temperature and the thermal resistance of the package. According to the datasheet, the maximum power dissipation is 1.4W at 25°C ambient temperature. However, it's recommended to derate the power dissipation based on the actual operating conditions.
  • The LT1006CN8 is rated for operation up to 70°C ambient temperature. However, the device's performance and reliability may degrade at higher temperatures. If you need to operate the device at higher temperatures, consider using a heat sink or a thermally-enhanced package, and consult with Analog Devices' application engineers for guidance.
  • To troubleshoot issues with the LT1006CN8, start by checking the input voltage, output voltage, and current consumption. Verify that the device is properly biased and that the output capacitor is within the recommended range. Use an oscilloscope to check for oscillations or noise on the output. If the issue persists, consult the datasheet and application notes, or contact Analog Devices' technical support for assistance.

Trust Checks

This model has been provided by community users.
Community Provided
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored

LT1006CN8 Overview

Use the download button to access the LT1006CN8 schematic symbol, PCB footprint, and 3D model.
