LT1529IQ - Analog Devices

LT1529IQ Details

• Manufacturer Part Number:

  LT1529IQ

• Part Life Cycle Code:

  Obsolete

• ECCN Code:

  EAR99

• HTS Code:

  8542.39.00.60

• Manufacturer:

  Analog Devices Inc

• YTEOL:

  0

• Adjustability:

  ADJUSTABLE

• Dropout Voltage1-Max:

  0.95 V

• Dropout Voltage1-Nom:

  0.6 V

• JESD-30 Code:

  R-PZFM-T5

• JESD-609 Code:

  e0

• Length:

  10.22 mm

• Line Regulation-Max (%/V):

  0.026

• Load Regulation-Max(%):

  0.82%

• Moisture Sensitivity Level:

  1

• Number of Functions:

  1

• Number of Outputs:

  1

• Number of Terminals:

  5

• Operating Temperature TJ-Max:

  125 °C

• Operating Temperature TJ-Min:

  -45 °C

• Output Current1-Max:

  3 A

• Output Voltage1-Max:

  14 V

• Output Voltage1-Min:

  3.75 V

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  TO-263

• Package Equivalence Code:

  SMSIP5H,.6,67TB

• Package Shape:

  RECTANGULAR

• Package Style:

  FLANGE MOUNT

• Peak Reflow Temperature (Cel):

  235

• Qualification Status:

  Not Qualified

• Regulator Type:

  ADJUSTABLE POSITIVE SINGLE OUTPUT LDO REGULATOR

• Seated Height-Max:

  21.539 mm

• Surface Mount:

  NO

• Technology:

  BIPOLAR

• Terminal Finish:

  Tin/Lead (Sn/Pb) - with Nickel (Ni) barrier

• Terminal Form:

  THROUGH-HOLE

• Terminal Pitch:

  1.7 mm

• Terminal Position:

  ZIG-ZAG

• Time@Peak Reflow Temperature-Max (s):

  20

• Width:

  4.38 mm
