LT3960EMSE#WPBF - Analog Devices

LT3960EMSE#WPBF Details

• Manufacturer Part Number:

  LT3960EMSE#WPBF

• Brand Name:

  Analog Devices Inc

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Part Package Code:

  EXPOSED PAD MINI_SOIC

• Package Description:

  MSOP-10

• Pin Count:

  10

• Manufacturer Package Code:

  EXPOSED PAD MINI_SOIC

• HTS Code:

  8542.39.00.01

• Date Of Intro:

  2020-10-15

• Manufacturer:

  Analog Devices Inc

• YTEOL:

  8.5

• Data Rate:

  400 Mbps

• JESD-30 Code:

  S-PDSO-G10

• Length:

  3 mm

• Moisture Sensitivity Level:

  1

• Number of Functions:

  1

• Number of Terminals:

  10

• Number of Transceivers:

  1

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -40 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  HTSSOP

• Package Equivalence Code:

  TSSOP10,.2,20

• Package Shape:

  SQUARE

• Package Style:

  SMALL OUTLINE, HEAT SINK/SLUG, THIN PROFILE, SHRINK PITCH

• Screening Level:

  AEC-Q100

• Seated Height-Max:

  1.1 mm

• Supply Voltage-Nom:

  3.3 V

• Surface Mount:

  YES

• Technology:

  BIPOLAR

• Telecom IC Type:

  CAN TRANSCEIVER

• Terminal Form:

  GULL WING

• Terminal Pitch:

  0.5 mm

• Terminal Position:

  DUAL

• Width:

  3 mm
