LTC1542IDD#PBF - Analog Devices

Description: Analog Comparators uP OpAmp + Comparator

Download LTC1542IDD#PBF Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
LTC1542IDD#PBF - Analog Devices PCB footprint - Small Outline No-lead - Small Outline No-lead - LTC1542IDD#PBF
click to zoom
3D Models
LTC1542IDD#PBF - Analog Devices  - 3D model - Small Outline No-lead - LTC1542IDD#PBF
click to zoom

LTC1542IDD#PBF Details

  • Manufacturer Part Number:

    LTC1542IDD#PBF

  • Brand Name:

    Analog Devices Inc

  • Pbfree Code:

    No

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Package Description:

    3 X 3 MM, LEAD FREE, PLASTIC, MO-229-WEED, DFN-8

  • Pin Count:

    8

  • Manufacturer Package Code:

    05-08-1698

  • Country Of Origin:

    Malaysia

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.39.00.01

  • Manufacturer:

    Analog Devices Inc

  • YTEOL:

    9

  • Additional Feature:

    CAN ALSO OPERATE WITH 5V SUPPLY

  • Analog IC - Other Type:

    ANALOG CIRCUIT

  • JESD-30 Code:

    S-PDSO-N8

  • JESD-609 Code:

    e3

  • Length:

    3 mm

  • Moisture Sensitivity Level:

    1

  • Number of Functions:

    1

  • Number of Terminals:

    8

  • Operating Temperature-Max:

    85 °C

  • Operating Temperature-Min:

    -40 °C

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Code:

    HVSON

  • Package Shape:

    SQUARE

  • Package Style:

    SMALL OUTLINE, HEAT SINK/SLUG, VERY THIN PROFILE

  • Peak Reflow Temperature (Cel):

    260

  • Qualification Status:

    Not Qualified

  • Seated Height-Max:

    0.85 mm

  • Supply Voltage-Max (Vsup):

    12.6 V

  • Supply Voltage-Min (Vsup):

    2.5 V

  • Supply Voltage-Nom (Vsup):

    3 V

  • Surface Mount:

    YES

  • Technology:

    CMOS

  • Temperature Grade:

    INDUSTRIAL

  • Terminal Finish:

    Matte Tin (Sn) - annealed

  • Terminal Form:

    NO LEAD

  • Terminal Pitch:

    0.5 mm

  • Terminal Position:

    DUAL

  • Time@Peak Reflow Temperature-Max (s):

    30

  • Width:

    3 mm

LTC1542IDD#PBF Frequently Asked Questions (FAQs)

  • The recommended layout and placement for the LTC1542IDD#PBF involves keeping the device away from high-frequency noise sources, using a solid ground plane, and placing the input and output capacitors close to the device. Additionally, it's recommended to use a low-ESR capacitor for the VCC bypass capacitor and to keep the analog and digital grounds separate.
  • The LTC1542IDD#PBF requires a single 2.7V to 5.5V power supply. It's recommended to power the device with a low-noise, low-dropout regulator. The power sequencing requirements involve powering the device after the analog input signals are present and stable, and ensuring that the power supply is stable before enabling the device.
  • The maximum allowable input voltage range for the LTC1542IDD#PBF is from -0.3V to VCC + 0.3V. Exceeding this range can cause the device to malfunction or be damaged. It's recommended to ensure that the input voltage is within the specified range to maintain optimal performance and prevent damage to the device.
  • To optimize the performance of the LTC1542IDD#PBF in high-frequency applications, it's recommended to use a low-ESR capacitor for the VCC bypass capacitor, minimize the length of the input and output traces, and use a solid ground plane. Additionally, it's recommended to use a high-frequency-compatible layout and to minimize the number of vias and layer changes.
  • The LTC1542IDD#PBF has a maximum junction temperature of 150°C. To ensure proper heat dissipation, it's recommended to use a thermal pad or heat sink, and to ensure good airflow around the device. Additionally, it's recommended to minimize the power consumption and to use a low-power mode when possible.
