LTC2672HCB-16#TRPBF - Analog Devices

LTC2672HCB-16#TRPBF Details

• Manufacturer Part Number:

  LTC2672HCB-16#TRPBF

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  WLCSP-36

• HTS Code:

  8542.39.00.40

• Manufacturer:

  Analog Devices Inc

• Converter Type:

  D/A CONVERTER

• Input Bit Code:

  BINARY

• Input Format:

  SERIAL

• JESD-30 Code:

  S-XBCS-B36

• Length:

  3.53 mm

• Linearity Error-Max (EL):

  0.09765625%

• Negative Supply Voltage-Nom:

  -3.3 V

• Number of Bits:

  16

• Number of Functions:

  1

• Number of Terminals:

  36

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -40 °C

• Package Body Material:

  UNSPECIFIED

• Package Code:

  UFBCS

• Package Equivalence Code:

  BGA36,6X6,20

• Package Shape:

  RECTANGULAR

• Package Style:

  CHIP SCALE, ULTRA THIN PROFILE, FINE PITCH

• Packing Method:

  TR

• Seated Height-Max:

  0.66 mm

• Settling Time-Nom (tstl):

  200 µs

• Supply Current-Max:

  5.3 mA

• Supply Voltage-Nom:

  5 V

• Surface Mount:

  YES

• Terminal Form:

  BALL

• Terminal Pitch:

  0.5 mm

• Terminal Position:

  BOTTOM

• Width:

  3.479 mm
