LTC3128EUFD#TRPBF - Analog Devices

Description: Switching Voltage Regulators 3A Monolithic Buck-Boost Supercapacitor Charger and Balancer with Accurate Input Current Limit

Download LTC3128EUFD#TRPBF Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
Send part feedback
Symbol
LTC3128EUFD#TRPBF - Analog Devices - PCB symbol
click to zoom
PCB Footprints
LTC3128EUFD#TRPBF - Analog Devices PCB footprint - Quad Flat No-Lead - Quad Flat No-Lead - UFD - 20-Lead Plastic QFN (4mm x 5mm)
click to zoom
3D Models
LTC3128EUFD#TRPBF - Analog Devices - 3D model - Quad Flat No-Lead - UFD - 20-Lead Plastic QFN (4mm x 5mm)
click to zoom

LTC3128EUFD#TRPBF Details

  • Manufacturer Part Number:

    LTC3128EUFD#TRPBF

  • Brand Name:

    Analog Devices Inc

  • Pbfree Code:

    No

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Package Description:

    4 X 5 MM, 0.75 MM HEIGHT, LEAD FREE, PLASTIC, MO-220WXXX-X, QFN-20

  • Pin Count:

    20

  • Manufacturer Package Code:

    05-08-1711

  • Country Of Origin:

    Thailand

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.39.00.01

  • Manufacturer:

    Analog Devices Inc

  • YTEOL:

    10

  • Additional Feature:

    OUTPUT VOLTAGE RANGE FROM 1.8 V TO 5.5 V

  • Analog IC - Other Type:

    SWITCHED CAPACITOR CONVERTER

  • Control Mode:

    CURRENT-MODE

  • Control Technique:

    PULSE WIDTH MODULATION

  • Input Voltage-Max:

    5.5 V

  • Input Voltage-Min:

    1.73 V

  • Input Voltage-Nom:

    3.3 V

  • JESD-30 Code:

    R-PQCC-N20

  • JESD-609 Code:

    e3

  • Length:

    5 mm

  • Moisture Sensitivity Level:

    1

  • Number of Functions:

    1

  • Number of Terminals:

    20

  • Operating Temperature-Max:

    85 °C

  • Output Current-Max:

    9 A

  • Output Voltage-Max:

    5.5 V

  • Output Voltage-Min:

    1.8 V

  • Output Voltage-Nom:

    4.8 V

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Code:

    HVQCCN

  • Package Shape:

    RECTANGULAR

  • Package Style:

    CHIP CARRIER, HEAT SINK/SLUG, VERY THIN PROFILE

  • Seated Height-Max:

    0.8 mm

  • Surface Mount:

    YES

  • Switcher Configuration:

    BUCK-BOOST

  • Switching Frequency-Max:

    1400 kHz

  • Technology:

    CMOS

  • Temperature Grade:

    OTHER

  • Terminal Finish:

    Matte Tin (Sn)

  • Terminal Form:

    NO LEAD

  • Terminal Pitch:

    0.5 mm

  • Terminal Position:

    QUAD

  • Width:

    4 mm

LTC3128EUFD#TRPBF Frequently Asked Questions (FAQs)

  • The maximum input voltage that can be applied to the LTC3128EUFD is 38V, but it's recommended to keep it below 36V for reliable operation.
  • To optimize inductor selection, consider the inductor's saturation current, DC resistance, and core material. A good starting point is to choose an inductor with a saturation current at least 1.5 times the peak current, and a DC resistance less than 100mΩ.
  • To minimize noise and EMI, keep the input and output capacitors close to the IC, use a solid ground plane, and keep the high-frequency switching nodes (e.g., LX and SW) away from sensitive analog nodes. Also, use a shielded inductor and orient it to minimize radiation.
  • To configure the LTC3128EUFD for a specific output voltage, use the VOUT pin to set the output voltage. Connect a resistive divider from VOUT to GND, and calculate the resistor values using the formula: R1 = (VOUT - 0.8V) / 10μA and R2 = 0.8V / 10μA.
  • The thermal derating of the LTC3128EUFD is 26.3mW/°C. To calculate the maximum ambient temperature, use the formula: TAmax = TJmax - (PD / θJA), where TJmax is the maximum junction temperature (150°C), PD is the power dissipation, and θJA is the junction-to-ambient thermal resistance (45°C/W).
