LTC3526BEDC#TRMPBF - Analog Devices

Description: 500mA 1MHz Synchronous Step-Up DC/DC Converters in 2mm ?? 2mm DFN

Download LTC3526BEDC#TRMPBF Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
LTC3526BEDC#TRMPBF - Analog Devices PCB footprint - Small Outline No-lead - Small Outline No-lead - DC6 Package 6-Lead Plastic DFN (2mm × 2mm) (Reference LTC DWG # 05-08-1703 Rev C)
click to zoom
3D Models
LTC3526BEDC#TRMPBF - Analog Devices  - 3D model - Small Outline No-lead - DC6 Package 6-Lead Plastic DFN (2mm × 2mm) (Reference LTC DWG # 05-08-1703 Rev C)
click to zoom

LTC3526BEDC#TRMPBF Details

  • Manufacturer Part Number:

    LTC3526BEDC#TRMPBF

  • Brand Name:

    Analog Devices Inc

  • Pbfree Code:

    No

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Not Recommended

  • Package Description:

    2 X 2 MM, 0.75 MM HEIGHT, LEAD FREE, PLASTIC, MO-229WCCD-2, DFN-6

  • Pin Count:

    6

  • Manufacturer Package Code:

    05-08-1703

  • Country Of Origin:

    Malaysia

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.39.00.01

  • Manufacturer:

    Analog Devices Inc

  • YTEOL:

    3

  • Additional Feature:

    ALSO OPERATES IN ADJUSTABLE MODE FROM 1.6V TO 5.25V

  • Analog IC - Other Type:

    SWITCHING CONTROLLER

  • Control Mode:

    CURRENT-MODE

  • Control Technique:

    PULSE WIDTH MODULATION

  • Input Voltage-Min:

    1 V

  • Input Voltage-Nom:

    1.2 V

  • JESD-30 Code:

    S-PDSO-N6

  • JESD-609 Code:

    e3

  • Length:

    2 mm

  • Moisture Sensitivity Level:

    1

  • Number of Functions:

    1

  • Number of Terminals:

    6

  • Operating Temperature-Max:

    85 °C

  • Output Current-Max:

    0.5 A

  • Output Voltage-Max:

    5.25 V

  • Output Voltage-Min:

    1.6 V

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Code:

    HVSON

  • Package Shape:

    SQUARE

  • Package Style:

    SMALL OUTLINE, HEAT SINK/SLUG, VERY THIN PROFILE

  • Peak Reflow Temperature (Cel):

    260

  • Qualification Status:

    Not Qualified

  • Seated Height-Max:

    0.8 mm

  • Surface Mount:

    YES

  • Switcher Configuration:

    BOOST

  • Switching Frequency-Max:

    1300 kHz

  • Technology:

    CMOS

  • Temperature Grade:

    OTHER

  • Terminal Finish:

    Matte Tin (Sn) - annealed

  • Terminal Form:

    NO LEAD

  • Terminal Pitch:

    0.5 mm

  • Terminal Position:

    DUAL

  • Time@Peak Reflow Temperature-Max (s):

    30

  • Width:

    2 mm

LTC3526BEDC#TRMPBF Frequently Asked Questions (FAQs)

  • The maximum input voltage that can be applied to the LTC3526 is 18V, but it's recommended to keep it below 15V for optimal performance and reliability.
  • To optimize the inductor selection, consider the inductor's saturation current, DC resistance, and core loss. A good starting point is to choose an inductor with a saturation current rating above the peak current of the converter, and a DC resistance that minimizes losses. The datasheet provides a list of recommended inductors.
  • The minimum ESR required for the output capacitor depends on the output voltage and current. As a general rule, a lower ESR capacitor is recommended for higher output currents. The datasheet provides a guideline for selecting the output capacitor, but a good starting point is to choose a capacitor with an ESR of 10mΩ or less.
  • To minimize noise and EMI, follow good PCB layout practices such as separating the power and signal grounds, using a solid ground plane, and keeping the switching node (SW pin) away from sensitive analog nodes. The datasheet provides a recommended PCB layout and guidelines for minimizing noise and EMI.
  • The thermal derating of the LTC3526 is typically 1.5°C/W, which means that the device's power dissipation should be derated by 1.5°C for every watt of power dissipation above 25°C. This is to ensure reliable operation and prevent overheating.
