LTC6263HMS#PBF - Analog Devices

Description: 30MHz, 240µA Power Efficient Rail-to-Rail I/O Op Amps

Download LTC6263HMS#PBF Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
Send part feedback
Symbol
LTC6263HMS#PBF - Analog Devices - PCB symbol
click to zoom
PCB Footprints
LTC6263HMS#PBF - Analog Devices PCB footprint - Small Outline Packages - Small Outline Packages - 16 Lead Plastic MSOP
click to zoom
3D Models
LTC6263HMS#PBF - Analog Devices - 3D model - Small Outline Packages - 16 Lead Plastic MSOP
click to zoom

LTC6263HMS#PBF Details

  • Manufacturer Part Number:

    LTC6263HMS#PBF

  • Brand Name:

    Analog Devices Inc

  • Pbfree Code:

    No

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Obsolete

  • Package Description:

    MSOP-16

  • Pin Count:

    16

  • Manufacturer Package Code:

    05-08-1669

  • Country Of Origin:

    Malaysia

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.33.00.01

  • Manufacturer:

    Analog Devices Inc

  • YTEOL:

    0

  • Amplifier Type:

    OPERATIONAL AMPLIFIER

  • Architecture:

    VOLTAGE-FEEDBACK

  • Average Bias Current-Max (IIB):

    0.15 µA

  • Bias Current-Max (IIB) @25C:

    0.05 µA

  • Common-mode Reject Ratio-Min:

    70 dB

  • Common-mode Reject Ratio-Nom:

    90 dB

  • Frequency Compensation:

    YES

  • Input Offset Voltage-Max:

    1000 µV

  • JESD-30 Code:

    R-PDSO-G16

  • JESD-609 Code:

    e3

  • Length:

    4.039 mm

  • Low-Bias:

    NO

  • Low-Offset:

    YES

  • Micropower:

    YES

  • Moisture Sensitivity Level:

    1

  • Number of Functions:

    4

  • Number of Terminals:

    16

  • Operating Temperature-Max:

    125 °C

  • Operating Temperature-Min:

    -40 °C

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Code:

    TSSOP

  • Package Shape:

    RECTANGULAR

  • Package Style:

    SMALL OUTLINE, THIN PROFILE, SHRINK PITCH

  • Power:

    NO

  • Programmable Power:

    NO

  • Seated Height-Max:

    1.1 mm

  • Slew Rate-Nom:

    6.5 V/us

  • Supply Current-Max:

    0.3 mA

  • Supply Voltage Limit-Max:

    5.5 V

  • Supply Voltage-Nom (Vsup):

    1.8 V

  • Surface Mount:

    YES

  • Technology:

    CMOS

  • Temperature Grade:

    AUTOMOTIVE

  • Terminal Finish:

    Matte Tin (Sn)

  • Terminal Form:

    GULL WING

  • Terminal Pitch:

    0.5 mm

  • Terminal Position:

    DUAL

  • Unity Gain BW-Nom:

    28000

  • Voltage Gain-Min:

    10000

  • Wideband:

    NO

  • Width:

    3 mm

LTC6263HMS#PBF Frequently Asked Questions (FAQs)

  • A good PCB layout for the LTC6263HMS involves keeping the input and output traces short and away from each other, using a solid ground plane, and placing the bypass capacitors close to the device. A 4-layer PCB with a dedicated ground plane is recommended. Additionally, the datasheet provides a recommended PCB layout and land pattern that should be followed.
  • The input and output capacitors should be chosen based on the operating frequency, input voltage, and output current requirements. A general rule of thumb is to use X7R or X5R ceramic capacitors with a voltage rating of at least 2x the input voltage. The datasheet provides guidelines for capacitor selection, and it's recommended to consult with an applications engineer if unsure.
  • The LTC6263HMS has an operating temperature range of -40°C to 125°C. However, the device's performance may degrade at higher temperatures, and the output voltage may droop. It's recommended to derate the output current and voltage at higher temperatures to ensure reliable operation.
  • To ensure stability, it's essential to follow the recommended PCB layout and component selection guidelines. Additionally, the input and output capacitors should be chosen to provide sufficient filtering and decoupling. The datasheet provides a stability analysis and recommends a minimum output capacitance of 10uF to ensure stability.
  • The typical startup time for the LTC6263HMS is around 100us to 200us, depending on the input voltage and output current requirements. However, this time can be affected by the input voltage rise time, output capacitance, and other factors. The datasheet provides more information on startup time and recommends using a soft-start circuit to reduce inrush current.
