LTC6560HUD#PBF - Analog Devices

Description: IC TRANSIMPEDANCE AMP 16QFN

Download LTC6560HUD#PBF Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
Send part feedback
Symbol
LTC6560HUD#PBF - Analog Devices - PCB symbol
click to zoom
PCB Footprints
LTC6560HUD#PBF - Analog Devices PCB footprint - Quad Flat No-Lead - Quad Flat No-Lead - 16-QFN (3x3)
click to zoom
3D Models
LTC6560HUD#PBF - Analog Devices - 3D model - Quad Flat No-Lead - 16-QFN (3x3)
click to zoom

LTC6560HUD#PBF Details

  • Manufacturer Part Number:

    LTC6560HUD#PBF

  • Brand Name:

    Analog Devices Inc

  • Pbfree Code:

    No

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Package Description:

    QFN-16

  • Pin Count:

    16

  • Manufacturer Package Code:

    05-08-1700

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.39.00.01

  • Date Of Intro:

    2019-02-15

  • Manufacturer:

    Analog Devices Inc

  • YTEOL:

    9

  • Analog IC - Other Type:

    ANALOG CIRCUIT

  • JESD-30 Code:

    S-PQCC-N16

  • JESD-609 Code:

    e3

  • Length:

    3 mm

  • Moisture Sensitivity Level:

    1

  • Number of Functions:

    1

  • Number of Terminals:

    16

  • Operating Temperature-Max:

    125 °C

  • Operating Temperature-Min:

    -40 °C

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Code:

    HVQCCN

  • Package Shape:

    SQUARE

  • Package Style:

    CHIP CARRIER, HEAT SINK/SLUG, VERY THIN PROFILE

  • Peak Reflow Temperature (Cel):

    260

  • Seated Height-Max:

    0.8 mm

  • Supply Voltage-Max (Vsup):

    5.25 V

  • Supply Voltage-Min (Vsup):

    4.75 V

  • Supply Voltage-Nom (Vsup):

    5 V

  • Surface Mount:

    YES

  • Technology:

    CMOS

  • Temperature Grade:

    AUTOMOTIVE

  • Terminal Finish:

    Matte Tin (Sn)

  • Terminal Form:

    NO LEAD

  • Terminal Pitch:

    0.5 mm

  • Terminal Position:

    QUAD

  • Width:

    3 mm

LTC6560HUD#PBF Frequently Asked Questions (FAQs)

  • A good PCB layout for the LTC6560HUD involves keeping the input and output traces short and away from each other, using a solid ground plane, and placing the bypass capacitors close to the device. A 4-layer PCB with a dedicated ground plane is recommended. Additionally, the datasheet provides a recommended PCB layout and land pattern that should be followed.
  • To ensure stability, it's essential to follow the recommended component values and PCB layout. Additionally, the output capacitor should be chosen carefully to ensure it meets the minimum ESR and capacitance requirements. The datasheet provides a stability analysis and a calculator tool to help with component selection. It's also recommended to simulate the design using SPICE models before building the prototype.
  • The maximum input voltage that can be applied to the LTC6560HUD is 5.5V. Exceeding this voltage can cause damage to the device. It's essential to ensure that the input voltage is within the recommended range to maintain the device's reliability and performance.
  • The LTC6560HUD is rated for operation up to 125°C junction temperature. However, the device's performance and reliability may degrade at high temperatures. It's essential to follow the recommended operating conditions and derate the device's performance accordingly. Additionally, the device's thermal management should be considered to ensure the junction temperature remains within the recommended range.
  • Troubleshooting issues with the LTC6560HUD involves following a systematic approach. First, ensure that the device is properly powered and the input voltage is within the recommended range. Next, check the output voltage and current to ensure they are within the expected range. Use an oscilloscope to check for oscillations or noise on the output. Finally, consult the datasheet and application notes for guidance on troubleshooting common issues.
