LTC6946IUFD-2#PBF - Analog Devices

Description: IC INTEGER-N PLL W/VCO 28-QFN

Download LTC6946IUFD-2#PBF Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
Send part feedback
Symbol
LTC6946IUFD-2#PBF - Analog Devices - PCB symbol
click to zoom
PCB Footprints
LTC6946IUFD-2#PBF - Analog Devices PCB footprint - Quad Flat No-Lead - Quad Flat No-Lead - UFD (28-Lead QFN)25
click to zoom
3D Models
LTC6946IUFD-2#PBF - Analog Devices - 3D model - Quad Flat No-Lead - UFD (28-Lead QFN)25
click to zoom

LTC6946IUFD-2#PBF Details

  • Manufacturer Part Number:

    LTC6946IUFD-2#PBF

  • Brand Name:

    Analog Devices Inc

  • Pbfree Code:

    No

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Obsolete

  • Package Description:

    4 X 5MM, LEAD FREE, PLASTIC, MO-220WXXX-X, QFN-28

  • Pin Count:

    28

  • Manufacturer Package Code:

    05-08-1712

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.39.00.01

  • Manufacturer:

    Analog Devices Inc

  • YTEOL:

    0

  • Additional Feature:

    ALSO OPERATES IN SUPPLY VOLTAGE 4 TO 5.25V

  • Analog IC - Other Type:

    PLL FREQUENCY SYNTHESIZER

  • JESD-30 Code:

    R-PQCC-N28
