LTC6950IUHH#PBF - Analog Devices

Description: Clock Synthesizer / Jitter Cleaner Integer-N PLL with 5 outputs

Download LTC6950IUHH#PBF Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
Send part feedback
Symbol
LTC6950IUHH#PBF - Analog Devices - PCB symbol
click to zoom
PCB Footprints
LTC6950IUHH#PBF - Analog Devices PCB footprint - Quad Flat No-Lead - Quad Flat No-Lead - 48-LEAD-[LFCSP_VQ]-
click to zoom
3D Models
LTC6950IUHH#PBF - Analog Devices - 3D model - Quad Flat No-Lead - 48-LEAD-[LFCSP_VQ]-
click to zoom

LTC6950IUHH#PBF Details

  • Manufacturer Part Number:

    LTC6950IUHH#PBF

  • Brand Name:

    Analog Devices Inc

  • Pbfree Code:

    No

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Obsolete

  • Package Description:

    5 X 9 MM, LEAD FREE, PLASTIC, QFN-48

  • Pin Count:

    48

  • Manufacturer Package Code:

    05-08-1845

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.39.00.01

  • Manufacturer:

    Analog Devices Inc

  • YTEOL:

    0

  • Analog IC - Other Type:

    PLL FREQUENCY SYNTHESIZER

  • JESD-30 Code:

    R-PQCC-N48

  • JESD-609 Code:

    e3

  • Length:

    9 mm

  • Moisture Sensitivity Level:

    1

  • Number of Functions:

    1

  • Number of Terminals:

    48

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Code:

    HVQCCN

  • Package Shape:

    RECTANGULAR

  • Package Style:

    CHIP CARRIER, HEAT SINK/SLUG, VERY THIN PROFILE

  • Seated Height-Max:

    0.8 mm

  • Supply Voltage-Max (Vsup):

    3.45 V

  • Supply Voltage-Min (Vsup):

    3.15 V

  • Supply Voltage-Nom (Vsup):

    3.3 V

  • Surface Mount:

    YES

  • Technology:

    CMOS

  • Terminal Finish:

    Matte Tin (Sn) - annealed

  • Terminal Form:

    NO LEAD

  • Terminal Pitch:

    0.5 mm

  • Terminal Position:

    QUAD

  • Width:

    5 mm

LTC6950IUHH#PBF Frequently Asked Questions (FAQs)

  • A good PCB layout for the LTC6950IUHH#PBF involves keeping the analog and digital grounds separate, using a solid ground plane, and placing the device close to the power supply. Additionally, it's recommended to use a 4-layer PCB with a dedicated layer for the analog signals, and to keep the signal traces short and direct.
  • The LTC6950IUHH#PBF requires a single 3.3V or 5V power supply, and it's recommended to use a low-noise, low-dropout regulator. The power sequencing requirements involve powering up the device in the following order: VCC, then AVCC, and finally the digital inputs. It's also important to ensure that the power supply is stable and well-regulated.
  • The LTC6950IUHH#PBF has a maximum junction temperature of 150°C, and it's recommended to keep the device temperature below 125°C for optimal performance. To prevent overheating, ensure good airflow around the device, use a heat sink if necessary, and avoid blocking the airflow around the device.
  • To configure the LTC6950IUHH#PBF for optimal clock jitter performance, use a high-quality clock source, ensure the device is properly terminated, and use the internal clock multiplier to minimize jitter. Additionally, use a low-jitter reference clock and ensure the device is operated within its specified frequency range.
  • To ensure EMI and RFI compliance, use a shielded enclosure, keep the device away from antennas and other EMI sources, and use EMI filters on the input and output signals. Additionally, follow good PCB layout practices, use a common mode choke, and ensure the device is operated within its specified frequency range.
