LTC6954IUFF-4#PBF - Analog Devices

LTC6954IUFF-4#PBF Details

• Manufacturer Part Number:

  LTC6954IUFF-4#PBF

• Brand Name:

  Analog Devices Inc

• Pbfree Code:

  No

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• Package Description:

  QFN-36

• Pin Count:

  36

• Manufacturer Package Code:

  05-08-1863

• Country Of Origin:

  Thailand

• ECCN Code:

  EAR99

• HTS Code:

  8542.39.00.01

• Manufacturer:

  Analog Devices Inc

• YTEOL:

  0

• Family:

  LTC6954

• Input Conditioning:

  SCHMITT TRIGGER

• JESD-30 Code:

  R-PQCC-N36

• JESD-609 Code:

  e3

• Length:

  7 mm

• Load Capacitance (CL):

  10 pF

• Logic IC Type:

  CLOCK DRIVER/DIVIDER

• Max I(ol):

  2.5 A

• Moisture Sensitivity Level:

  1

• Number of Functions:

  3

• Number of Inverted Outputs:

  3

• Number of Terminals:

  36

• Number of True Outputs:

  3

• Operating Temperature-Max:

  105 °C

• Operating Temperature-Min:

  -40 °C

• Output Characteristics:

  3-STATE

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  HVQCCN

• Package Equivalence Code:

  LCC36,.16X.28,20

• Package Shape:

  RECTANGULAR

• Package Style:

  CHIP CARRIER, HEAT SINK/SLUG, VERY THIN PROFILE

• Power Supply Current-Max (ICC):

  315 mA

• Prop. Delay@Nom-Sup:

  0.625 ns

• Propagation Delay (tpd):

  0.625 ns

• Same Edge Skew-Max (tskwd):

  0.12 ns

• Seated Height-Max:

  0.8 mm

• Supply Voltage-Max (Vsup):

  3.45 V

• Supply Voltage-Min (Vsup):

  3.15 V

• Supply Voltage-Nom (Vsup):

  3.3 V

• Surface Mount:

  YES

• Technology:

  CMOS

• Temperature Grade:

  INDUSTRIAL

• Terminal Finish:

  Matte Tin (Sn)

• Terminal Form:

  NO LEAD

• Terminal Pitch:

  0.5 mm

• Terminal Position:

  QUAD

• Width:

  4 mm

• fmax-Min:

  1400 MHz
