LTKAK6-058C - LITTELFUSE

LTKAK6-058C Details

• Manufacturer Part Number:

  LTKAK6-058C

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• HTS Code:

  8541.10.00.50

• Manufacturer:

  Littelfuse Inc

• Breakdown Voltage-Max:

  70 V

• Breakdown Voltage-Min:

  64 V

• Breakdown Voltage-Nom:

  67 V

• Clamping Voltage-Max:

  110 V

• Configuration:

  SINGLE

• Diode Element Material:

  SILICON

• Diode Type:

  TRANS VOLTAGE SUPPRESSOR DIODE

• JESD-30 Code:

  R-PSSO-C1

• Non-rep Peak Rev Power Dis-Max:

  660000 W

• Number of Elements:

  1

• Number of Terminals:

  1

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -55 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE

• Peak Reflow Temperature (Cel):

  NOT SPECIFIED

• Polarity:

  BIDIRECTIONAL

• Reference Standard:

  IEC-61000-4-5; MIL-STD-202; UL RECOGNIZED

• Rep Pk Reverse Voltage-Max:

  58 V

• Reverse Current-Max:

  10 µA

• Reverse Test Voltage:

  58 V

• Surface Mount:

  YES

• Technology:

  AVALANCHE

• Terminal Form:

  C BEND

• Terminal Position:

  SINGLE

• Time@Peak Reflow Temperature-Max (s):

  NOT SPECIFIED
