LTM4663EV#PBF - Analog Devices

LTM4663EV#PBF Details

• Manufacturer Part Number:

  LTM4663EV#PBF

• Brand Name:

  Analog Devices Inc

• Pbfree Code:

  No

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  LGA-25

• Pin Count:

  25

• Manufacturer Package Code:

  05-08-1785

• ECCN Code:

  EAR99

• HTS Code:

  8473.30.11.80

• Date Of Intro:

  2020-04-13

• Manufacturer:

  Analog Devices Inc

• YTEOL:

  9

• Analog IC - Other Type:

  SWITCHING REGULATOR

• Control Mode:

  VOLTAGE-MODE

• Control Technique:

  PULSE WIDTH MODULATION

• Input Voltage-Max:

  5.5 V

• Input Voltage-Min:

  2.7 V

• Input Voltage-Nom:

  5 V

• JESD-30 Code:

  R-PBGA-B25

• JESD-609 Code:

  e4

• Length:

  4 mm

• Moisture Sensitivity Level:

  3

• Number of Functions:

  1

• Number of Terminals:

  25

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -40 °C

• Output Current-Max:

  1.5 A

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  TFLGA

• Package Equivalence Code:

  LGA25,5X5,25

• Package Shape:

  RECTANGULAR

• Package Style:

  GRID ARRAY, THIN PROFILE, FINE PITCH

• Peak Reflow Temperature (Cel):

  260

• Seated Height-Max:

  1.4 mm

• Surface Mount:

  YES

• Switching Frequency-Max:

  2000 kHz

• Technology:

  HYBRID

• Temperature Grade:

  AUTOMOTIVE

• Terminal Finish:

  Gold (Au)

• Terminal Form:

  BUTT

• Terminal Pitch:

  0.65 mm

• Terminal Position:

  BOTTOM

• Width:

  3.5 mm
