LX7178-01CSP - Microsemi Corporation

LX7178-01CSP Details

• Manufacturer Part Number:

  LX7178-01CSP

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Transferred

• ECCN Code:

  EAR99

• HTS Code:

  8542.39.00.60

• Manufacturer:

  Microsemi Corporation (now Microchip)

• Analog IC - Other Type:

  SWITCHING REGULATOR

• Control Mode:

  VOLTAGE-MODE

• JESD-30 Code:

  R-PBGA-B20

• Number of Terminals:

  20

• Operating Temperature-Max:

  85 °C

• Output Current-Max:

  5 A

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  FBGA

• Package Equivalence Code:

  BGA20,4X5,16

• Package Shape:

  RECTANGULAR

• Package Style:

  GRID ARRAY, FINE PITCH

• Qualification Status:

  Not Qualified

• Surface Mount:

  YES

• Switching Frequency-Max:

  2250 kHz

• Temperature Grade:

  OTHER

• Terminal Form:

  BALL

• Terminal Pitch:

  0.4 mm

• Terminal Position:

  BOTTOM
