M2022SS2W30 - NKK Switches

M2022SS2W30 Details

• Manufacturer Part Number:

  M2022SS2W30

• Brand Name:

  NKK Switches

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• ECCN Code:

  EAR99

• HTS Code:

  8536.50.90.65

• Manufacturer:

  NKK Switches

• YTEOL:

  0

• Actuator Length:

  0.413 inch

• Actuator Type:

  SMALL BAT TYPE

• Additional Feature:

  PANEL MOUNTABLE

• Body Breadth:

  12.7 mm

• Body Height:

  12.7 mm

• Body Length or Diameter:

  13 mm

• Bushing Diameter:

  0.244 inch

• Bushing Length:

  0.35 inch

• Contact (AC) Max Rating R Load:

  6A@125VAC

• Contact Current(AC)-Max:

  6 A

• Contact Current(DC)-Max:

  4 A

• Contact (DC) Max Rating R Load:

  4A@30VDC

• Contact Voltage(AC)-Max:

  125 V

• Contact Voltage(DC)-Max:

  30 V

• Electrical Life:

  25000 Cycle(s)

• Illumination:

  NON-ILLUMINATED

• Mounting Feature:

  THROUGH HOLE-RIGHT ANGLE

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -30 °C

• Sealing:

  EPOXY TERMINAL SEALED; MOISTURE PROOF

• Surface Mount:

  NO

• Switch Action:

  LATCHED

• Switch Function:

  DPDT

• Switch Type:

  TOGGLE SWITCH

• Termination Type:

  SOLDER
