M2TP80M12W2-2LA - STMicroelectronics

M2TP80M12W2-2LA Details

• Manufacturer Part Number:

  M2TP80M12W2-2LA

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Country Of Origin:

  Mainland China

• ECCN Code:

  EAR99

• Manufacturer:

  STMicroelectronics

• YTEOL:

  7

• Case Connection:

  ISOLATED

• Configuration:

  COMPLEX

• DS Breakdown Voltage-Min:

  1200 V

• Drain Current-Max (ID):

  30 A

• Drain-source On Resistance-Max:

  0.114 Ω

• FET Technology:

  METAL-OXIDE SEMICONDUCTOR

• Feedback Cap-Max (Crss):

  15 pF

• JESD-30 Code:

  R-PDIP-T32

• JESD-609 Code:

  e3

• Number of Elements:

  6

• Number of Terminals:

  32

• Operating Mode:

  ENHANCEMENT MODE

• Operating Temperature-Max:

  175 °C

• Operating Temperature-Min:

  -40 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Shape:

  RECTANGULAR

• Package Style:

  IN-LINE

• Peak Reflow Temperature (Cel):

  245

• Polarity/Channel Type:

  N-CHANNEL

• Pulsed Drain Current-Max (IDM):

  58 A

• Reference Standard:

  AQG-324

• Surface Mount:

  YES

• Terminal Finish:

  Matte Tin (Sn) - annealed

• Terminal Form:

  THROUGH-HOLE

• Terminal Position:

  DUAL

• Transistor Application:

  SWITCHING

• Transistor Element Material:

  SILICON CARBIDE
