M39016/31-003M - TE Connectivity

M39016/31-003M Details

• Manufacturer Part Number:

  M39016/31-003M

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• HTS Code:

  8536.41.00.20

• Factory Lead Time:

  44 Weeks, 6 Days

• Manufacturer:

  TE Connectivity

• Body Breadth:

  15.5 mm

• Body Height:

  8.13 mm

• Body Length or Diameter:

  15.5 mm

• Coil Operate Voltage(DC):

  13.5 V

• Coil Power:

  720 mW

• Coil Resistance:

  975 Ω

• Coil Voltage(DC)-Max:

  26.5 V

• Coil Voltage-Nom:

  26.5 V

• Coil/Input Supply Type:

  DC

• Contact Current(AC)-Max:

  2 A

• Contact Current(DC)-Max:

  2 A

• Contact (DC) Max Rating R Load:

  2A@28VDC

• Contact Voltage(DC)-Max:

  28 V

• Electrical Life:

  100000 Cycle(s)

• Input Switching Control Type:

  Random

• Mounting Feature:

  PANEL MOUNT

• Number of Terminals:

  16

• Operate Time:

  4 ms

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -65 °C

• Physical Dimension:

  15.5mm x 15.5mm x 8.13mm

• Relay Form:

  4 FORM C

• Relay Function:

  4PDT-CO

• Sealing:

  HERMETICALLY SEALED

• Surface Mount:

  NO

• Terminal Length:

  0.004699009398018796 inch

• Termination Type:

  SOLDER
