MA5519-ALD - COILCRAFT

MA5519-ALD Details

• Manufacturer Part Number:

  MA5519-ALD

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• Manufacturer:

  Coilcraft Inc

• YTEOL:

  8

• Additional Feature:

  LENGTH AND BREADTH DIMENSIONS INCLUDE TERMINAL ALSO

• Height:

  17.5 mm

• Input Voltage-Max:

  75 V

• Input Voltage-Min:

  36 V

• Length:

  34.7 mm

• Mounting Feature:

  SURFACE MOUNT

• Number of Primary Winding:

  1

• Number of Secondary Winding:

  1

• Operating Frequency-Max:

  700 kHz

• Operating Temperature-Max:

  120 °C

• Operating Temperature-Min:

  -40 °C

• Output Voltage 1:

  12 V

• Packing Method:

  TR, EMBOSSED PLASTIC, 13 INCH

• Power Rating:

  720 W

• Primary Inductance:

  190.8 µH

• Surface Mount:

  YES

• Transformer Type:

  SMPS TRANSFORMER

• Width:

  34 mm
