MAAM-011289-TR0500 - MACOM

Description: RF Amplifier IC VSAT 28GHz ~ 30GHz 12-AQFN (3x3)

Download MAAM-011289-TR0500 Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
MAAM-011289-TR0500 - MACOM PCB footprint - Quad Flat No-Lead - Quad Flat No-Lead - 3 mm 12-Lead AQFN
click to zoom
3D Models
MAAM-011289-TR0500 - MACOM  - 3D model - Quad Flat No-Lead - 3 mm 12-Lead AQFN
click to zoom

MAAM-011289-TR0500 Details

  • Manufacturer Part Number:

    MAAM-011289-TR0500

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Package Description:

    QFN-12

  • Manufacturer:

    MACOM

  • YTEOL:

    8

  • Characteristic Impedance:

    50 Ω

  • Construction:

    COMPONENT

  • Gain:

    14 dB

  • Input Power-Max (CW):

    15 dBm

  • Mounting Feature:

    SURFACE MOUNT

  • Number of Functions:

    1

  • Number of Terminals:

    12

  • Operating Frequency-Max:

    20000 MHz

  • Operating Frequency-Min:

    5000 MHz

  • Operating Temperature-Max:

    85 °C

  • Operating Temperature-Min:

    -40 °C

  • Package Equivalence Code:

    LCC12,.12SQ,20

  • Power Supplies:

    5 V

  • RF/Microwave Device Type:

    WIDE BAND MEDIUM POWER

  • Supply Current-Max:

    130 mA

  • Surface Mount:

    YES

  • VSWR-Max:

    1.5

MAAM-011289-TR0500 Frequently Asked Questions (FAQs)

  • MACOM recommends a 4-layer PCB with a solid ground plane, and thermal vias under the device to dissipate heat. A thermal pad on the bottom of the package should be connected to a heat sink or a thermal management system.
  • The device requires a bias tee or a DC block to provide the correct voltage and current. A bias voltage of 5V to 12V is recommended, and the current limit should be set to 500mA to 1A, depending on the application.
  • MACOM recommends using a conjugate match at the input and output ports to achieve optimal performance. A 50Ω system is recommended, and the matching network should be designed to provide a return loss of at least 15dB.
  • The device is ESD sensitive, so it's essential to handle it with ESD-safe materials and tools. A wrist strap or ESD mat should be used during assembly, and the device should be stored in an ESD-safe container when not in use.
  • The recommended operating temperature range for the MAAM-011289-TR0500 is -40°C to 85°C. Operating the device outside this range may affect its performance and reliability.
