MAAP-011313 - MACOM

MAAP-011313 Details

• Manufacturer Part Number:

  MAAP-011313

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  QFN-32

• Date Of Intro:

  2020-07-15

• Manufacturer:

  MACOM

• YTEOL:

  7

• Characteristic Impedance:

  50 Ω

• Construction:

  COMPONENT

• Gain:

  34 dB

• Input Power-Max (CW):

  23 dBm

• JESD-609 Code:

  e4

• Mounting Feature:

  SURFACE MOUNT

• Number of Functions:

  1

• Number of Terminals:

  32

• Operating Frequency-Max:

  15000 MHz

• Operating Frequency-Min:

  13500 MHz

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Equivalence Code:

  LCC32,.2SQ,20

• Power Supplies:

  6 V

• RF/Microwave Device Type:

  WIDE BAND HIGH POWER

• Surface Mount:

  YES

• Technology:

  PHEMT

• Terminal Finish:

  NICKEL PALLADIUM GOLD

• VSWR-Max:

  1.43
