MACOM recommends a 4-layer PCB with a solid ground plane, and thermal vias under the package to dissipate heat. A thermal pad on the bottom of the package should be connected to a heat sink or a thermal management system.
Use a combination of simulation tools and empirical methods to optimize the input and output matching networks. MACOM provides a reference design and application notes to help with the optimization process.
Operate the MAAP-118260 within the recommended temperature range of -40°C to 85°C, and ensure the device is not exposed to moisture or humidity. Follow MACOM's recommended storage and handling procedures to prevent damage.
Use a systematic approach to troubleshoot, starting with a review of the PCB layout, component values, and soldering quality. Check for signs of overheating, and verify that the device is operated within the recommended specifications.
Yes, the MAAP-118260 is a sensitive device and requires proper ESD protection during handling and assembly. Use an ESD wrist strap, mat, or workstation, and follow MACOM's recommended handling procedures to prevent damage.
Trust Checks
This model has been provided by community users.
Community Provided
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored
MAAP-118260 Overview
Use the download button to access the MAAP-118260 schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like MAAP-,
or try a keyword search, such as RF/Microwave Amplifiers
