MASTERGAN1L - STMicroelectronics

MASTERGAN1L Details

• Manufacturer Part Number:

  MASTERGAN1L

• Part Life Cycle Code:

  Active

• Package Description:

  QFN-31

• Country Of Origin:

  Thailand

• ECCN Code:

  EAR99

• HTS Code:

  8542.39.00.60

• Manufacturer:

  STMicroelectronics

• YTEOL:

  8

• High Side Driver:

  YES

• Input Characteristics:

  SCHMITT TRIGGER

• Interface IC Type:

  HALF BRIDGE BASED GAN FET DRIVER

• JESD-30 Code:

  S-XQCC-N31

• Length:

  9 mm

• Number of Functions:

  1

• Number of Terminals:

  31

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -40 °C

• Output Characteristics:

  PUSH-PULL

• Output Peak Current Limit-Nom:

  17 A

• Package Body Material:

  UNSPECIFIED

• Package Code:

  HVQCCN

• Package Equivalence Code:

  LCC31,.35SQ,25

• Package Shape:

  SQUARE

• Package Style:

  CHIP CARRIER, HEAT SINK/SLUG, VERY THIN PROFILE

• Seated Height-Max:

  1 mm

• Supply Voltage-Max:

  9.5 V

• Supply Voltage-Min:

  4.75 V

• Supply Voltage-Nom:

  6 V

• Supply Voltage1-Max:

  8.5 V

• Supply Voltage1-Min:

  3 V

• Supply Voltage1-Nom:

  6 V

• Surface Mount:

  YES

• Terminal Form:

  NO LEAD

• Terminal Pitch:

  0.6 mm

• Terminal Position:

  QUAD

• Turn-off Time:

  0.045 µs

• Turn-on Time:

  0.045 µs

• Width:

  9 mm
