MAX1910EUB+ - Analog Devices

Description: LED Lighting Drivers 1.5x/2x High-Efficiency White LED Charge Pumps

Download MAX1910EUB+ Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
Send part feedback
Symbol
MAX1910EUB+ - Analog Devices - PCB symbol
click to zoom
PCB Footprints
MAX1910EUB+ - Analog Devices PCB footprint - Small Outline Packages - Small Outline Packages - MAX1910EUB+
click to zoom
3D Models
MAX1910EUB+ - Analog Devices - 3D model - Small Outline Packages - MAX1910EUB+
click to zoom

MAX1910EUB+ Details

  • Manufacturer Part Number:

    MAX1910EUB+

  • Brand Name:

    Analog Devices Inc

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Part Package Code:

    10-MINI_SO-N/A

  • Package Description:

    MICRO, SOP-10

  • Pin Count:

    10

  • Manufacturer Package Code:

    10-MINI_SO-N/A

  • Country Of Origin:

    Japan, Mainland China, Malaysia, Philippines, Singapore, South Korea, Taiwan, Thailand, USA

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.39.00.60

  • Date Of Intro:

    2002-06-15

  • Manufacturer:

    Analog Devices Inc

  • YTEOL:

    8.5

  • Analog IC - Other Type:

    SWITCHED CAPACITOR REGULATOR

  • Input Voltage-Max:

    5.3 V

  • Input Voltage-Min:

    2.7 V

  • Input Voltage-Nom:

    3.6 V

  • JESD-30 Code:

    S-PDSO-G10

  • JESD-609 Code:

    e3

  • Length:

    3 mm

  • Moisture Sensitivity Level:

    1

  • Number of Functions:

    1

  • Number of Terminals:

    10

  • Operating Temperature-Max:

    85 °C

  • Operating Temperature-Min:

    -40 °C

  • Output Current-Max:

    0.08 A

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Code:

    TSSOP

  • Package Equivalence Code:

    TSSOP10,.19,20

  • Package Shape:

    SQUARE

  • Package Style:

    SMALL OUTLINE, THIN PROFILE, SHRINK PITCH

  • Peak Reflow Temperature (Cel):

    260

  • Qualification Status:

    Not Qualified

  • Seated Height-Max:

    1.1 mm

  • Surface Mount:

    YES

  • Switcher Configuration:

    DOUBLER INVERTER

  • Switching Frequency-Max:

    875 kHz

  • Technology:

    BICMOS

  • Temperature Grade:

    INDUSTRIAL

  • Terminal Finish:

    Matte Tin (Sn) - annealed

  • Terminal Form:

    GULL WING

  • Terminal Pitch:

    0.5 mm

  • Terminal Position:

    DUAL

  • Time@Peak Reflow Temperature-Max (s):

    30

  • Width:

    3 mm

MAX1910EUB+ Frequently Asked Questions (FAQs)

  • The recommended layout and placement for the MAX1910EUB+ involves keeping the device away from high-current carrying traces, using a solid ground plane, and placing the input and output capacitors close to the device. Additionally, it's recommended to use a 4-layer PCB with a dedicated power plane and a dedicated ground plane to minimize noise and EMI.
  • To optimize the performance of the MAX1910EUB+ in a high-temperature environment, it's recommended to use a heat sink, ensure good airflow, and reduce the power dissipation of the device. Additionally, the device's thermal shutdown feature can be used to prevent damage from overheating.
  • The maximum input voltage that the MAX1910EUB+ can handle is 28V, but it's recommended to operate the device within the specified input voltage range of 4.5V to 24V to ensure reliable operation and to prevent damage to the device.
  • To troubleshoot issues with the MAX1910EUB+, it's recommended to check the input voltage, output voltage, and current, as well as the device's thermal shutdown and overcurrent protection features. Additionally, checking the PCB layout and component placement can help identify any issues related to noise, EMI, or thermal performance.
  • Yes, the MAX1910EUB+ can be used in a redundant or hot-swappable power supply configuration, but it's recommended to use external circuitry to ensure that the device is properly synchronized and that the output voltage is stable during transitions.
