MAX4951AECTP+ - Analog Devices

Description: Buffers & Line Drivers SATA I/II Bidirectional Redriver with High ESD and Cable Detect

Download MAX4951AECTP+ Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
MAX4951AECTP+ - Analog Devices PCB footprint - Quad Flat No-Lead - Quad Flat No-Lead - T2044-2
click to zoom
3D Models
MAX4951AECTP+ - Analog Devices  - 3D model - Quad Flat No-Lead - T2044-2
click to zoom

MAX4951AECTP+ Details

  • Manufacturer Part Number:

    MAX4951AECTP+

  • Brand Name:

    Analog Devices Inc

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Obsolete

  • Part Package Code:

    20-LFCSP-4X4X0.75

  • Pin Count:

    20

  • Manufacturer Package Code:

    20-LFCSP-4X4X0.75

  • Country Of Origin:

    Japan, Mainland China, Malaysia, Philippines, Singapore, South Korea, Taiwan, Thailand, USA

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.39.00.60

  • Date Of Intro:

    2009-08-11

  • Manufacturer:

    Analog Devices Inc

  • YTEOL:

    0

  • Interface IC Type:

    BUFFER OR INVERTER BASED PERIPHERAL DRIVER

  • JESD-609 Code:

    e3

  • Moisture Sensitivity Level:

    1

  • Peak Reflow Temperature (Cel):

    260

  • Terminal Finish:

    Matte Tin (Sn) - annealed

  • Time@Peak Reflow Temperature-Max (s):

    30

MAX4951AECTP+ Frequently Asked Questions (FAQs)

  • A good PCB layout is crucial for the MAX4951AECTP+. Ensure a solid ground plane, keep the input and output traces short and separate, and use a common-mode choke or ferrite bead to filter out high-frequency noise.
  • Choose input capacitors with low ESR and high ripple current rating. For output capacitors, select ones with low ESR, high capacitance, and a voltage rating that meets or exceeds the output voltage. Consult the datasheet for specific recommendations.
  • The MAX4951AECTP+ is rated for operation up to 85°C ambient temperature. However, it's recommended to derate the device for reliable operation above 70°C. Consult the datasheet for thermal derating guidelines.
  • Follow proper PCB layout and design guidelines, use shielding and filtering components, and ensure the device is properly decoupled. Consult the datasheet and relevant EMC standards (e.g., EN 55022) for specific guidance.
  • The recommended input voltage range for the MAX4951AECTP+ is 4.5V to 5.5V. Operating outside this range may affect performance, efficiency, or reliability.
