MAX5855EXE+ Details

• Manufacturer Part Number:

  MAX5855EXE+

• Brand Name:

  Analog Devices Inc

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• Part Package Code:

  144-CSP_BGA-10X10X1.17

• Package Description:

  FCCSP-144

• Pin Count:

  144

• Manufacturer Package Code:

  144-CSP_BGA-10X10X1.17

• Country Of Origin:

  Japan, Mainland China, Malaysia, Philippines, Singapore, South Korea, Taiwan, Thailand, USA

• HTS Code:

  8542.39.00.40

• Date Of Intro:

  2018-11-21

• Manufacturer:

  Analog Devices Inc

• YTEOL:

  0

• Analog Output Voltage-Max:

  2.2 V

• Analog Output Voltage-Min:

  1.4 V

• Converter Type:

  D/A CONVERTER

• Input Bit Code:

  OFFSET BINARY

• Input Format:

  SERIAL

• JESD-30 Code:

  S-PBGA-B144

• Length:

  10 mm

• Moisture Sensitivity Level:

  3

• Number of Bits:

  16

• Number of Functions:

  1

• Number of Terminals:

  144

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  LFBGA

• Package Equivalence Code:

  bga144,12X12,32

• Package Shape:

  SQUARE

• Package Style:

  GRID ARRAY, LOW PROFILE, FINE PITCH

• Seated Height-Max:

  1.265 mm

• Settling Time-Nom (tstl):

  0.02 µs

• Supply Current-Max:

  270 mA

• Supply Voltage-Nom:

  1 V

• Surface Mount:

  YES

• Temperature Grade:

  INDUSTRIAL

• Terminal Form:

  BALL

• Terminal Pitch:

  0.8 mm

• Terminal Position:

  BOTTOM

• Width:

  10 mm
