MAX5876EGK+D - Analog Devices

MAX5876EGK+D Details

• Manufacturer Part Number:

  MAX5876EGK+D

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  ,

• Reach Compliance Code:

  Compliant

• HTS Code:

  8542.39.00.40

• Manufacturer:

  Analog Devices Inc

• YTEOL:

  9

• Analog Output Voltage-Max:

  1.1 V

• Analog Output Voltage-Min:

  -0.5 V

• Converter Type:

  D/A CONVERTER

• Input Bit Code:

  OFFSET BINARY, 2'S COMPLEMENT BINARY

• Input Format:

  PARALLEL, WORD

• JESD-30 Code:

  S-PQCC-N68

• Length:

  10 mm

• Linearity Error-Max (EL):

  0.00488%

• Number of Bits:

  12

• Number of Functions:

  1

• Number of Terminals:

  68

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  HVQCCN

• Package Equivalence Code:

  LCC68,.4SQ,20

• Package Shape:

  SQUARE

• Package Style:

  CHIP CARRIER, HEAT SINK/SLUG, VERY THIN PROFILE

• Packing Method:

  DRY PACK

• Seated Height-Max:

  1 mm

• Settling Time-Nom (tstl):

  0.014 µs

• Supply Current-Max:

  58 mA

• Supply Voltage-Nom:

  1.8 V

• Surface Mount:

  YES

• Terminal Form:

  NO LEAD

• Terminal Pitch:

  0.5 mm

• Terminal Position:

  QUAD

• Width:

  10 mm
