MAX8627ETD+T - Analog Devices

Description: Switching Voltage Regulators Low VBATT, 20uA IQ, 1MHz Synchronous Boo

Download MAX8627ETD+T Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
MAX8627ETD+T - Analog Devices PCB footprint - Small Outline No-lead - Small Outline No-lead - T1433-2
click to zoom
3D Models
MAX8627ETD+T - Analog Devices  - 3D model - Small Outline No-lead - T1433-2
click to zoom

MAX8627ETD+T Details

  • Manufacturer Part Number:

    MAX8627ETD+T

  • Brand Name:

    Analog Devices Inc

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Part Package Code:

    14-LFCSP-3X3X0.75

  • Package Description:

    3 X 3 MM, 0.80 MM HEIGHT, LEAD FREE, TDFN-14

  • Pin Count:

    14

  • Manufacturer Package Code:

    14-LFCSP-3X3X0.75

  • Country Of Origin:

    Japan, Mainland China, Malaysia, Philippines, Singapore, South Korea, Taiwan, Thailand, USA

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.39.00.60

  • Date Of Intro:

    2006-04-12

  • Manufacturer:

    Analog Devices Inc

  • YTEOL:

    10

  • Analog IC - Other Type:

    BATTERY CHARGE CONTROLLER
