MAX98090AEWJ+T Frequently Asked Questions (FAQs)

• What is the recommended PCB layout for optimal performance of the MAX98090AEWJ+T?
  A good PCB layout for the MAX98090AEWJ+T involves keeping the analog and digital grounds separate, using a solid ground plane, and minimizing the length of the traces between the device and the capacitors. Additionally, it's recommended to place the device near the audio codec and use a shielded cable for the audio signals.
• How do I configure the MAX98090AEWJ+T for a specific audio application?
  The MAX98090AEWJ+T can be configured using the I2C interface. The device has several registers that control the audio settings, such as gain, mute, and volume. The specific configuration will depend on the application requirements, but Analog Devices provides a detailed programming guide in the datasheet and application notes.
• What is the maximum power consumption of the MAX98090AEWJ+T?
  The maximum power consumption of the MAX98090AEWJ+T depends on the operating mode and the supply voltage. According to the datasheet, the typical power consumption is around 12mA at 1.8V supply voltage, but it can go up to 20mA in certain configurations. It's recommended to check the datasheet and application notes for more detailed information.
• Is the MAX98090AEWJ+T compatible with other audio codecs?
  The MAX98090AEWJ+T is designed to work with the MAX9867/MAX9868 audio codecs, but it can also be used with other audio codecs that have a similar interface and functionality. However, compatibility should be verified through testing and validation, and Analog Devices may provide additional support and guidance for specific use cases.
• What is the thermal management strategy for the MAX98090AEWJ+T?
  The MAX98090AEWJ+T has a thermal pad on the bottom of the package that should be connected to a solid ground plane on the PCB to dissipate heat. Additionally, the device has a thermal shutdown feature that will turn off the device if the junction temperature exceeds 150°C. It's recommended to follow the thermal management guidelines in the datasheet and application notes to ensure reliable operation.
