MBR5H60PC-AU_R2_000A1 - PANJIT

MBR5H60PC-AU_R2_000A1 Details

• Manufacturer Part Number:

  MBR5H60PC-AU_R2_000A1

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• Manufacturer:

  PanJit Semiconductor

• Additional Feature:

  LOW LEAKAGE CURRENT, LOW POWER LOSS

• Application:

  EFFICIENCY

• Breakdown Voltage-Min:

  60 V

• Case Connection:

  CATHODE

• Configuration:

  SINGLE

• Diode Element Material:

  SILICON

• Diode Type:

  RECTIFIER DIODE

• Forward Voltage-Max (VF):

  0.75 V

• JEDEC-95 Code:

  TO-277C

• JESD-30 Code:

  R-PDSO-F3

• Non-rep Pk Forward Current-Max:

  190 A

• Number of Elements:

  1

• Number of Phases:

  1

• Number of Terminals:

  3

• Operating Temperature-Max:

  175 °C

• Operating Temperature-Min:

  -55 °C

• Output Current-Max:

  5 A

• Package Body Material:

  PLASTIC/EPOXY

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE

• Packing Method:

  TR, 13 INCH

• Reference Standard:

  AEC-Q101; IEC-61249; MIL-STD-750

• Rep Pk Reverse Voltage-Max:

  60 V

• Reverse Current-Max:

  5 µA

• Reverse Test Voltage:

  60 V

• Surface Mount:

  YES

• Technology:

  SCHOTTKY

• Terminal Form:

  FLAT

• Terminal Position:

  DUAL
