MC07XSG517EK - NXP

Description: Power Switch ICs - Power Distribution High-Side Switch, 18V, Triple 7mOhms + Dual 17mOhms, SOICEP 54

Download MC07XSG517EK Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
Send part feedback
Symbol
MC07XSG517EK - NXP - PCB symbol
click to zoom
PCB Footprints
MC07XSG517EK - NXP PCB footprint - Small Outline Packages - Small Outline Packages - SOIC-52+
click to zoom
3D Models
MC07XSG517EK - NXP - 3D model - Small Outline Packages - SOIC-52+
click to zoom

MC07XSG517EK Details

  • Manufacturer Part Number:

    MC07XSG517EK

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Obsolete

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.39.00.60

  • Factory Lead Time:

    4 Weeks

  • Manufacturer:

    NXP Semiconductors

  • YTEOL:

    0

  • Interface IC Type:

    BUFFER OR INVERTER BASED PERIPHERAL DRIVER

  • JESD-609 Code:

    e3

  • Moisture Sensitivity Level:

    3

  • Peak Reflow Temperature (Cel):

    260

  • Terminal Finish:

    Tin (Sn)

  • Time@Peak Reflow Temperature-Max (s):

    40
