- Part Number MC14468P
- Manufacturer NXP
- Pin Count 16
- Part Category Integrated Circuit
- Package Category Dual-In-Line Packages
- Footprint Name Dual-In-Line Packages - CASE 648-08 ISSUE R 16-LEAD PLASTIC DIP
- Released Date Jan 27, 2021
- Last Modified Date Mar 7, 2023 4:10 PM UTC
- Pinout / Pin List Click Here (Member Only)
MC14468P Details
-
Manufacturer Part Number:
MC14468P
-
Part Life Cycle Code:
Obsolete
-
Package Description:
DIP-16
-
HTS Code:
8542.39.00.01
-
Manufacturer:
NXP Semiconductors
-
YTEOL:
0
-
Analog IC - Other Type:
ANALOG CIRCUIT
-
JESD-30 Code:
R-PDIP-T16
-
Number of Functions:
1
-
Number of Terminals:
16
-
Operating Temperature-Max:
60 °C
