MC145503DW - Motorola

MC145503DW Details

• Manufacturer Part Number:

  MC145503DW

• Part Life Cycle Code:

  Obsolete

• Package Description:

  PLASTIC, SOP-16

• HTS Code:

  8542.39.00.01

• Manufacturer:

  Motorola Semiconductor Products

• YTEOL:

  0

• Companding Law:

  A/MU-LAW

• Filter:

  YES

• Gain Tolerance-Max:

  0.3 dB

• JESD-30 Code:

  R-PDSO-G16

• JESD-609 Code:

  e0

• Length:

  10.3 mm

• Linear Coding:

  NOT AVAILABLE

• Number of Functions:

  1

• Number of Terminals:

  16

• Operating Mode:

  ASYNCHRONOUS

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  SOP

• Package Equivalence Code:

  SOP16,.4

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE

• Qualification Status:

  Not Qualified

• Seated Height-Max:

  2.65 mm

• Supply Current-Max:

  9 mA

• Supply Voltage-Nom:

  12 V

• Surface Mount:

  YES

• Technology:

  CMOS

• Telecom IC Type:

  PCM CODEC

• Temperature Grade:

  INDUSTRIAL

• Terminal Finish:

  TIN LEAD

• Terminal Form:

  GULL WING

• Terminal Pitch:

  1.27 mm

• Terminal Position:

  DUAL

• Width:

  7.5 mm
