MC146805E2CPS - Motorola

MC146805E2CPS Details

• Manufacturer Part Number:

  MC146805E2CPS

• Part Life Cycle Code:

  Obsolete

• Package Description:

  DIP-40

• HTS Code:

  8542.31.00.15

• Manufacturer:

  Motorola Semiconductor Products

• YTEOL:

  0

• Bit Size:

  8

• CPU Family:

  6805

• JESD-30 Code:

  R-PDIP-T40

• JESD-609 Code:

  e0

• Number of Terminals:

  40

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  DIP

• Package Equivalence Code:

  DIP40,.6

• Package Shape:

  RECTANGULAR

• Package Style:

  IN-LINE

• Qualification Status:

  Not Qualified

• RAM (bytes):

  112

• Speed:

  5 MHz

• Supply Current-Max:

  10 mA

• Surface Mount:

  NO

• Technology:

  CMOS

• Temperature Grade:

  INDUSTRIAL

• Terminal Finish:

  Tin/Lead (Sn/Pb)

• Terminal Form:

  THROUGH-HOLE

• Terminal Pitch:

  2.54 mm

• Terminal Position:

  DUAL
