MC25132 - Multicomp Pro

MC25132 Details

• Manufacturer Part Number:

  MC25132

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• HTS Code:

  8536.41.00.20

• Manufacturer:

  SPC Multicomp

• YTEOL:

  7

• Body Breadth:

  10 mm

• Body Height:

  11.5 mm

• Body Length or Diameter:

  20.3 mm

• Coil Current(DC)-Max:

  0.03 A

• Coil Operate Voltage(DC):

  3.75 V

• Coil Power:

  150 mW

• Coil Release Voltage(DC):

  0.5 V

• Coil Resistance:

  166 Ω

• Coil Voltage(DC)-Max:

  5 V

• Coil/Input Supply Type:

  DC

• Contact (AC) Max Rating R Load:

  1A@125VAC

• Contact Current(AC)-Max:

  1 A

• Contact Current(DC)-Max:

  1 A

• Contact (DC) Max Rating R Load:

  1A@30VDC

• Contact Voltage(AC)-Max:

  125 V

• Contact Voltage(DC)-Max:

  30 V

• Contact/Output Supply Type:

  AC/DC

• Electrical Life:

  100000 Cycle(s)

• Mounting Feature:

  THROUGH HOLE-STRAIGHT

• Operate Time:

  7 ms

• Operating Temperature-Max:

  70 °C

• Operating Temperature-Min:

  -25 °C

• Physical Dimension:

  20.3mm x 10mm x 11.5mm

• Relay Action:

  MOMENTARY

• Relay Function:

  DPDT

• Relay Type:

  POWER/SIGNAL RELAY

• Release Time:

  3 ms

• Surface Mount:

  NO

• Termination Type:

  SOLDER
