MC68302CRC20 - Motorola

MC68302CRC20 Details

• Manufacturer Part Number:

  MC68302CRC20

• Part Life Cycle Code:

  Obsolete

• Package Description:

  PGA-132

• HTS Code:

  8542.31.00.25

• Manufacturer:

  Motorola Semiconductor Products

• YTEOL:

  0

• Address Bus Width:

  23

• Bit Size:

  32

• Boundary Scan:

  NO

• Clock Frequency-Max:

  16.67 MHz

• External Data Bus Width:

  16

• Format:

  FIXED POINT

• Integrated Cache:

  NO

• JESD-30 Code:

  S-CPGA-P132

• JESD-609 Code:

  e0

• Length:

  34.545 mm

• Low Power Mode:

  YES

• Number of Terminals:

  132

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Package Body Material:

  CERAMIC, METAL-SEALED COFIRED

• Package Code:

  PGA

• Package Shape:

  SQUARE

• Package Style:

  GRID ARRAY

• Qualification Status:

  Not Qualified

• Seated Height-Max:

  3.81 mm

• Speed:

  20 MHz

• Supply Voltage-Max:

  5.5 V

• Supply Voltage-Min:

  4.5 V

• Supply Voltage-Nom:

  5 V

• Surface Mount:

  NO

• Technology:

  HCMOS

• Temperature Grade:

  INDUSTRIAL

• Terminal Finish:

  TIN LEAD

• Terminal Form:

  PIN/PEG

• Terminal Pitch:

  2.54 mm

• Terminal Position:

  PERPENDICULAR

• Width:

  34.545 mm

• uPs/uCs/Peripheral ICs Type:

  MICROPROCESSOR, RISC
