MC68HC705C8AP - Motorola

MC68HC705C8AP Details

• Manufacturer Part Number:

  MC68HC705C8AP

• Part Life Cycle Code:

  Obsolete

• Package Description:

  DIP-40

• HTS Code:

  8542.31.00.15

• Manufacturer:

  Motorola Semiconductor Products

• YTEOL:

  0

• Bit Size:

  8

• CPU Family:

  6805

• JESD-30 Code:

  R-PDIP-T40

• JESD-609 Code:

  e0

• Number of Terminals:

  40

• Operating Temperature-Max:

  70 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  DIP

• Package Equivalence Code:

  DIP40,.6

• Package Shape:

  RECTANGULAR

• Package Style:

  IN-LINE

• Qualification Status:

  Not Qualified

• RAM (bytes):

  176

• ROM (words):

  7744

• ROM Programmability:

  UVPROM

• Speed:

  2.1 MHz

• Supply Current-Max:

  7 mA

• Surface Mount:

  NO

• Technology:

  CMOS

• Temperature Grade:

  COMMERCIAL

• Terminal Finish:

  Tin/Lead (Sn/Pb)

• Terminal Form:

  THROUGH-HOLE

• Terminal Pitch:

  2.54 mm

• Terminal Position:

  DUAL
